2 Deep Equilibrium Nets

This chapter introduces Deep Equilibrium Nets (DEQNs), the central computational framework of this script. Rather than generating labeled training data, a DEQN embeds the equilibrium conditions of a dynamic stochastic model (Euler equations, budget constraints, complementarity conditions) directly into the loss function of a neural network. The network then learns policy functions by minimizing the violation of these conditions via gradient descent. We develop the methodology on the classical Brock--Mirman growth model, for which an analytical solution exists and serves as a benchmark. The primary reference is Azinovic et al. (2022).

2.0.0.1Notation transition.¶

Chapter Chapter 1 used $\bm{\theta}$ for the parameter vector of a generic supervised model, following the textbook convention. From this chapter onward we switch to $\rho$ (so that the network is denoted $\mathcal{N}_\rho(\x)$), matching the notation of Azinovic et al. (2022) and most of the subsequent DEQN literature. The two symbols denote the same object; we use $\rho$ for parameters wherever a network appears, and reserve $\bm{\theta}$ for structural economic parameters that the network does not see (Chs. Chapter 10--Chapter 11).

2.1The Curse of Dimensionality in Economics¶

A central challenge in computational economics is that many models of interest, such as overlapping-generations (OLG) economies, heterogeneous-agent models, and international business cycle models, feature state spaces of high dimension. In an OLG model with $N$ cohorts and idiosyncratic risk, the state vector may include individual capital holdings, productivity levels, and wealth shares for each cohort, leading to state spaces of dimension $d \gg 10$. Traditional grid-based solution methods, such as value function iteration on a Cartesian grid with $n$ nodes per dimension, require $n^d$ grid points; this is the curse of dimensionality, the term coined by Bellman (1961) to describe the exponential growth of computational cost with the number of state variables. A concrete back-of-the-envelope makes the bottleneck plain: at the modest resolution of $n=100$ nodes per dimension, a $d=5$ state space already requires $100^5 = 10^{10}$ grid points, which is infeasible under any reasonable compute budget; even more modest resolutions of $n=20$--30 become prohibitive once $d$ exceeds ten.

Table Table 2.1 illustrates the curse concretely. Even with a modest $n=10$ grid points per dimension, the total number of grid points grows astronomically.

2.1.0.1The volume paradox.¶

A complementary, and more geometric, perspective on the curse of dimensionality starts from a single ratio. The volume of the unit $d$-ball relative to the smallest cube that contains it, $[-1,1]^d$, is

This ratio collapses with $d$ (Figure Figure 2.1): it is $\pi/4 \approx 0.785$ at $d=2$ and $\pi/6 \approx 0.524$ at $d=3$, has fallen to $\approx 2.5\times 10^{-3}$ by $d=10$, and is below 10^-70 at $d=100$. The geometry behind the numbers is sharp. The inscribed ball touches the center of each of the $2d$ faces, at distance 1 from the center, but its surface never gets within $\sqrt{d}-1$ of any of the $2^d$ corners, which sit at distance $\sqrt{d}$. As $d$ grows the corners march off to infinity while the ball stays put, so essentially all of the cube’s volume drains into its corners, far from the center. A box-shaped object in high dimensions is, to a first approximation, all corners and no middle.

Why should an economist care about a fact about cubes and balls? Because solving a dynamic stochastic model means producing a global solution^[1], and the region over which that solution actually has to be accurate is the model’s ergodic set, the states the economy visits under its own law of motion. That set is typically a thin, curved, low-volume sliver of any hypercube $[\x_{\min},\x_{\max}]^d$ that one would draw around it, often well under one percent of the bounding box already at moderate $d$ Judd et al., 2011. Yet most of the high-dimensional approximation machinery on offer, tensor-product grids, adaptive sparse grids, tensor-product quadrature, is built on the hypercube; by the volume paradox an exponentially growing fraction of those nodes lands in corners the model never visits, so most of the computational effort is spent representing the function where it does not matter. Figure Figure 2.2 visualizes this mismatch. This is exactly the waste the DEQN approach is designed to avoid: instead of tiling a box, it trains the network on states sampled from the model’s own simulated trajectories, putting the approximation effort where the economics lives.

Distance itself is the second casualty of high dimensions, and it is worth flagging now because it returns later with teeth. Draw a point uniformly from the unit $d$-ball: its radius has cumulative distribution $r^d$ and density $d\,r^{d-1}$ on $[0,1]$, which for large $d$ piles essentially all of its mass against the shell $r\to 1$. Random points sit on the pulp, not in the core, and they do so with overwhelming probability. Relatedly, pairwise Euclidean distances among random points concentrate so tightly that the nearest and the farthest neighbor of a query point become almost equidistant, so “distance” loses most of its power to discriminate Aggarwal et al., 2001 (Figure Figure 2.3). This is not a curio: any method that judges similarity through $\|\x-\x'\|$, from $k$-nearest-neighbors to kernel ridge regression to the Gaussian-process surrogates of Chapter Chapter 9, whose RBF and Matérn kernels are functions of $\|\x-\x'\|$ alone, loses resolution as $d$ grows. It is one of the reasons Chapter Chapter 9 reaches for dimension reduction, active subspaces and deep kernels, before fitting a GP in a high-dimensional input space.

2.2From Supervised Learning to Self-Supervised Equilibrium Solving¶

A word on terminology before we start, recalling the taxonomy of Section Section 1.3. A learning method is supervised when its loss compares the network’s output to an externally given target label; it is unsupervised when there are no target labels at all (clustering, density estimation, dimension reduction); and it is self-supervised when, although no human-provided labels exist, the method manufactures its own supervisory target out of the available structure. Deep Equilibrium Nets are unsupervised in the narrow “no labels” sense, but the sharper and more useful description is equation-based self-supervision: at every state where we evaluate the model, the equilibrium conditions tell us what the correct relationship between today’s policy and tomorrow’s must be, namely a residual of zero, and that residual plays exactly the role a label plays in supervised learning. The DEQN objective introduced below is therefore a genuine regression loss, only against a target the model itself dictates rather than one handed to us as data.

With that in mind, the key conceptual shift introduced by Azinovic et al. (2022) is to replace the labeled training data of standard supervised learning with the structural equations of the economic model. In a generic dynamic stochastic economic model, the state of the economy at time $t$ is summarized by a vector $\x_t \in \R^d$, and agents choose policy (or decision) variables $p_t = p(\x_t) \in \R^m$. The equilibrium is characterized by a system of functional equations

where $G$ encodes optimality conditions (e.g., Euler equations) and $\mathbb{E}_t[\cdot]$ is the conditional expectation over next-period shocks via the transition law $\x_{t+1} = T(\x_t, p(\x_t), \varepsilon_{t+1})$. The fundamental challenge is that this is a functional equation: we seek functions $p:\R^d \to \R^m$ rather than finite-dimensional parameter vectors. The DEQN approach parameterizes $p$ as a neural network and solves this functional equation via stochastic optimization (Figure Figure 2.4).

In the standard (supervised) paradigm, one minimizes the discrepancy between the network’s predictions and known target values. In the DEQN framework, the loss function is instead the squared norm of the equilibrium residual:

where $\mathcal{N}_\rho$ denotes a deep neural network with parameters $\rho$ that maps states to policies. If the residual loss is zero on a sufficiently rich set of states and the conditional expectations inside $G$ are evaluated accurately (rather than with a single shock realization), the network satisfies the equilibrium conditions on those states; global accuracy must always be assessed on independent validation trajectories and, where available, against benchmark solutions. The continuous-time analogue is the residual-loss formulation of Raissi et al. (2019), which inspired the PINN literature developed in Chapter Chapter 7. The training points $\x_i$ are drawn not from an exogenous dataset, but from the model’s own simulated dynamics: the network learns on the ergodic distribution of the economy, concentrating computational effort on economically relevant regions of the state space. The idea of using simulated paths as the support for projection goes back to the parameterized-expectations algorithm of Marcet (1988) and Marcet & Marshall (1994), which the DEQN literature reframed as ergodic-set sampling to focus computation on economically relevant states; the numerical stability of stochastic-simulation projection was further developed by Judd et al. (2011).

2.2.0.1Connection to the modern overparameterized regime.¶

Note that DEQNs operate squarely in the “modern regime” of Section Section 1.10: the network often has $p \gg n$ parameters relative to the mini-batch size $n$. Unlike supervised learning with a fixed dataset, however, the training distribution is renewable: each episode can generate fresh state samples from the model’s own simulation. This changes the fixed-dataset double-descent analogy, but it does not remove the need for validation: $p$ can still exceed the effective sample budget seen during training, and a flexible network can fit residuals on a narrow simulated region. The practical lesson is to combine overparameterized networks and SGD with independent validation trajectories, held-out Euler residuals, and, where available, closed-form benchmarks.

2.3The DEQN Training Algorithm¶

Several features of this algorithm deserve emphasis:

• Endogenous training distribution. As the policy network improves, the simulated paths become more accurate, and the training points concentrate on the ergodic set of the true equilibrium. This is fundamentally different from supervised learning, where the training distribution is fixed. Early in training, however, the simulated distribution is generated by a poor and rapidly changing policy: it can be unstable, infeasible, or far too narrow. Practical implementations therefore (i) burn in with broad sampling from the prior or a uniform box around the deterministic steady state, (ii) clip or guard against infeasible states (e.g. negative consumption), and (iii) often maintain a small replay buffer so that early states are revisited as the policy improves. Out-of-sample validation on an independent trajectory remains essential.

• No labeled data. The algorithm requires no “ground truth” solutions, only the structural equations of the model. The loss function has direct economic interpretation: it measures the violation of equilibrium conditions.

• Stochastic optimization. Mini-batch SGD naturally handles the stochasticity of the model: different mini-batches sample different states, providing implicit exploration of the state space.

• Scalability. The DEQN avoids explicit tensor-product state grids entirely: the per-iteration cost scales with network size, batch size, the number of equations, and the cost of integrating the conditional expectation; the input/output layer widths and the simulation step also depend on the state and shock dimensions, but only linearly. This favorable empirical scaling does not eliminate all high-dimensional costs (sample complexity, expectation accuracy, optimization difficulty), but it does mitigate the practical grid-based curse of dimensionality.

• JIT-compile every gradient step. In any production or classroom-scale implementation, the per-batch gradient step (lines 5--6 inside the inner loop) should be wrapped in @tf.function (TensorFlow), torch.compile (PyTorch), or @jax.jit (JAX). The speed-up over an un-traced Python loop is typically 5--$50\times$ for the per-step kernel, and the trace cost is amortized after the first call. All companion notebooks in this course follow this convention; un-traced Python loops are simply too slow for classroom use, let alone for research-scale runs.

2.3.0.1Episode length $T_{\mathrm{sim}}$.¶

The simulated-trajectory length $T_{\mathrm{sim}}$ controls the effective size of the training set within an episode. Azinovic et al. (2022) use $T_{\mathrm{sim}} = 10{,}000$ time steps (split into many short mini-batches) in their 113-dimensional 56-agent OLG benchmark. Shorter episodes (e.g., $T_{\mathrm{sim}} = 1000$) speed up early training because the distribution is re-drawn more frequently, at the cost of higher variance; longer episodes produce smoother gradient estimates but run the risk of stale data if the policy has drifted during training. A pragmatic rule is to start short, lengthen $T_{\mathrm{sim}}$ as the loss plateaus, and check out-of-sample accuracy on an independent simulated trajectory.

2.3.0.2Connection to continuous-time methods.¶

The DEQN residual loss is the discrete-time analogue of the Deep Galerkin Method (DGM) of Sirignano & Spiliopoulos (2018), which minimizes a PDE residual on neural-network-parameterized PDE solutions in continuous time, and of the deep BSDE solver of Han et al. (2018) (Han--Jentzen--E), which formulates the same problem as a backward stochastic differential equation. Within the discrete-time deep-learning toolkit, Maliar et al. (2021) unify lifetime-reward, Bellman-equation, and Euler-equation training into a single framework, paired with an “all-in-one” integration operator that estimates all conditional expectations from a single Monte Carlo realization; DEQN as developed here is the Euler-equation branch of that taxonomy. Chapters Chapter 7 and Chapter 8 develop the continuous-time analogues explicitly; the present chapter should be read as introducing the discrete-time machinery on which those continuous-time methods are built.

2.4The Brock--Mirman Benchmark¶

Having laid out the generic training loop, we now put it to work on a concrete model. To validate the DEQN methodology, Azinovic et al. (2022) begin with the stochastic growth model of Brock & Mirman (1972), which admits a closed-form solution and therefore serves as an ideal test case.

The social planner solves:

where $\beta \in (0,1)$ is the discount factor, $\alpha \in (0,1)$ the capital share, $\varrho \in [0,1)$ the shock persistence, $\sigma_z > 0$ the shock volatility, and $\epsilon_{t+1} \sim \mathcal{N}(0,1)$ i.i.d. innovations. Depreciation is full ($\delta = 1$).

2.4.0.1Derivation of the Euler equation.¶

To derive the optimality conditions, form the Lagrangian by attaching a multiplier $\beta^t \lambda_t$ to the resource constraint at each date $t$:

Since the planner chooses $C_t$ and $K_{t+1}$ at each date, we take partial derivatives with respect to each:

FOC w.r.t. $C_t$:

FOC w.r.t. $K_{t+1}$: The variable $K_{t+1}$ appears in the date-$t$ constraint (with coefficient -1) and in the date-$(t\!+\!1)$ constraint via output $z_{t+1}K_{t+1}^\alpha$. Differentiating:

Dividing both sides by $\beta^t$ yields:

Finally, substituting $\lambda_t = 1/C_t$ from (2.6) into this expression gives the Euler equation:

The economic intuition is transparent: the left-hand side is the marginal utility cost of saving one additional unit today; the right-hand side is the expected discounted marginal utility gain from the extra output $\alpha\, z_{t+1}\, K_{t+1}^{\alpha-1}$ that unit produces tomorrow. At the optimum, the planner is indifferent between consuming and saving at the margin.

2.4.0.2Analytical solution.¶

When depreciation is full ($\delta = 1$), this model admits a closed-form solution. One can verify by direct substitution into the Euler equation (2.9) that the optimal consumption policy is:

The derivation proceeds by guessing that the value function takes the form $V(K,z) = V_0 + B\ln K + D\ln z$ (with the constant $V_0$ written as $V_0$ rather than $A$ to avoid clashing with the TFP / cohort-count uses of $A$ elsewhere in the script) and using the envelope theorem. Substituting this guess into the Bellman equation $V(K,z) = \max_C \{\ln C + \beta \E{V(K',z')}\}$ with $K' = zK^\alpha - C$ yields a system of equations for $V_0$, $B$, and $D$. Matching coefficients on $\ln K$ pins down $B = \alpha/(1-\alpha\beta)$; matching on $\ln z$ pins down $D = 1/[(1-\alpha\beta)(1-\beta\varrho)]$ (so $D$, unlike $B$, depends on the shock persistence); and the constant $V_0$ then absorbs the remaining terms. The first-order condition $1/C_t = \beta\,B/K_{t+1}$ together with $C_t + K_{t+1} = z_t K_t^\alpha$ delivers the linear savings rule $K_{t+1} = \beta\alpha\, z_t K_t^\alpha$, from which (2.10) follows immediately via the resource constraint. Notably, this closed-form solution holds regardless of the shock persistence $\varrho$ for the savings rule itself, because $z_{t+1}$ cancels in the ratio $z_{t+1}/C_{t+1}$ under the linear consumption rule: $C_{t+1} \propto z_{t+1}$, so $z_{t+1}/C_{t+1} = 1/[(1-\beta\alpha) K_{t+1}^\alpha]$ no longer depends on the next-period shock.

2.4.0.3Persistent shocks.¶

When $\varrho > 0$, productivity shocks are autocorrelated and the state of the economy becomes the pair $(K_t, z_t)$, since the current shock level $z_t$ now carries information about future productivity. Under log utility with Cobb--Douglas production and full depreciation ($\delta = 1$), the analytical solution (2.10) continues to hold regardless of the persistence $\varrho$. The reason fits in one line: under the linear consumption rule $C_t = (1-\beta\alpha)\,z_t K_t^\alpha$ we have $z_{t+1}/C_{t+1} = 1/[(1-\beta\alpha)K_{t+1}^\alpha]$, so $z_{t+1}$ cancels and the conditional expectation in the Euler equation (2.9) no longer depends on the next-period shock; the constant $D$ in the value function still depends on $\varrho$, but $D$ enters $V$ and cancels in the FOC for the savings rule. However, for more general preferences (e.g., CRRA with $\gamma \neq 1$), partial depreciation ($\delta < 1$), or non-Cobb--Douglas production, the closed-form solution breaks down and numerical methods, and the DEQN approach in particular, become essential: the policy function $C(K_t, z_t)$ must be approximated rather than derived analytically. (Concretely: the deterministic companion notebook uses $\delta = 1$ so that the closed form applies and can be used as a benchmark; the stochastic companion notebook switches to $\delta = 0.1$, where it does not, and the policy is genuinely learned. Only the loss-kernel notebook of Section 2.9 returns to $\delta = 1$, precisely so that the closed-form savings rate $s^\star = \alpha\beta$ is available as ground truth.)

2.4.0.4DEQN formulation.¶

We parametrize the consumption policy as $C_t = \mathcal{N}_\rho(K_t, z_t)$ and define the residual

where $z_{t+1}$ denotes a single realization of the next-period shock and $K_{t+1} = z_t K_t^\alpha - \mathcal{N}_\rho(K_t, z_t)$. In the code listing below the network actually emits a savings share $s_t\in(0,1)$ through a sigmoid head rather than $C_t$ directly, which guarantees $C_t>0$ and $K_{t+1}>0$ at every training step; Section Section 2.5 explains the hard-vs-soft constraint split this exemplifies. Note that the Euler equation (2.9) involves the conditional expectation $\mathbb{E}_t[\cdot]$, whereas the residual $G$ above is written for a single realization of $z_{t+1}$. Two approaches are common for handling this expectation:

1. Path averaging: draw a single $z_{t+1}$ per state, compute $G$ for that draw, and average $G^2$ over many states along the simulated path. This minimizes $\mathbb{E}_{(K_t,z_t,z_{t+1})}[G^2]$ -- the squared pathwise residual. It is an unbiased Monte Carlo objective for that stronger loss, and Jensen’s inequality gives $\bigl(\mathbb{E}_t[G]\bigr)^2 \leq \mathbb{E}_t[G^2]$. Thus $G=0$ almost surely implies the conditional Euler equation, but the converse need not hold: a policy can have $\mathbb{E}_t[G]=0$ while $G$ varies with the shock. In the log/full-depreciation Brock--Mirman benchmark the closed-form policy happens to drive the pathwise residual itself to zero, so this stronger target is harmless; in richer models it is a modeling choice. This is the approach used in the Brock--Mirman code listing below. Note that the pathwise-residual-zero coincidence is special to $\delta = 1$: for $\delta < 1$ (the calibration of the stochastic notebook) a converged policy has $\mathbb{E}_\varepsilon[G\mid x]=0$ but $G$ itself is nonzero realization-by-realization, so path averaging then minimizes a strictly stronger objective than the conditional Euler residual.

2. Quadrature: for each state $(K_t, z_t)$, approximate $\mathbb{E}_t[\cdot]$ explicitly via deterministic nodes and weights (Section Section 2.6), form the residual from the estimated expectation, and then square. This targets $\bigl(\mathbb{E}_t[G]\bigr)^2$ directly and is the approach used for the IRBC model of Chapter Chapter 3, where accurate expectations are critical for convergence.

Both approaches recover the analytical solution (2.10) to high accuracy, providing a rigorous validation of the methodology. Because convergence curves depend on the exact training run, random seed, and solver configuration, this manuscript does not include a hand-drawn convergence plot. In practice, one should report diagnostics from the actual notebook run: residual trajectories, held-out Euler errors, and the gap between the learned policy and the analytical benchmark. Figure Figure 2.5 sketches the qualitative shape one should expect to see.

2.4.0.5Relative Euler equation error.¶

Following Judd (1998) and Azinovic et al. (2022) (Eq. 43), the standard accuracy diagnostic for a DEQN is the relative Euler error, which measures the percentage consumption error implied by a violation of the Euler equation. For Brock--Mirman with log utility, the relative error at state $\x_j = (K_j, z_j)$ is

where $C_\rho = \mathcal{N}_\rho$, $K'_j$ is next-period capital under the network policy, the expectation conditions on $\x_j$, and the $^{-1}$ inverts the marginal-utility relation $u'(c) = 1/c$. The value $e^{\mathrm{REE}} = 10^{-4}$ means the agent’s optimal consumption is mispriced by $0.01\%$, independent of units or utility scale. This is the metric reported in Table 3 of Azinovic et al. (2022), where the trained DEQN achieves mean relative Euler errors of order 10^-4 on the 113-dimensional 56-agent OLG benchmark.

def deqn_loss(model, K, z, beta, alpha, z_next):
    Y       = z * K**alpha                   # output today
    s       = model(K, z)                    # savings share in (0,1) via sigmoid
    C       = (1.0 - s) * Y                  # consumption today  (>0)
    K_next  = s * Y                          # capital tomorrow   (>0)
    Y_next  = z_next * K_next**alpha
    s_next  = model(K_next, z_next)
    C_next  = (1.0 - s_next) * Y_next        # consumption tomorrow
    # z_next: single draw; expectation via path averaging
    G = 1.0 - beta * (C / C_next) * alpha * z_next * K_next**(alpha-1)
    return tf.reduce_mean(G**2)

A Gauss--Hermite variant (developed formally in Section 2.6.2) replaces the single shock draw z_next by a $Q$-node weighted sum $\mathrm{E}[\,\alpha z' K'^{\alpha-1}/C'\mid z\,] \approx \sum_{q=1}^{Q} w_q\,\alpha z_q' K'^{\alpha-1}/C'(K',z_q')$ with $z_q' = z^\varrho\exp(\sigma_z\varepsilon_q)$ at the rescaled Hermite nodes $\varepsilon_q$; in practice $Q=5$ already drives the quadrature error below the training error. The autodiff companion notebook 03_Brock_Mirman_Uncertainty_AutoDiff_DEQN.ipynb implements this variant explicitly.

2.5Encoding Equilibrium Conditions: Hard vs. Soft Constraints¶

The Brock--Mirman DEQN loss above already used one design choice without dwelling on it: the network emits a savings share through a sigmoid rather than consumption directly. This is an instance of a general principle. Azinovic et al. (2022) §4.2.2 do not treat every equilibrium equation symmetrically in the loss (2.3); they split the conditions into two groups. We make the split explicit on the Brock--Mirman model of the previous section and then indicate how it generalizes.

Hard constraints, encoded in the architecture (never in the loss).

Some equations can be satisfied exactly for every state $\x = (K,z)$:

• The resource / state-transition equation $K_{t+1} = z_t K_t^\alpha - C_t$ defines next-period capital from the network’s consumption policy. It is not minimized; it is evaluated as a closed-form function of $\x_t$ and $C_t$.

• The economic requirements $C_t > 0$ and $K_{t+1} > 0$ are jointly imposed by parameterizing the network’s output as a savings share $s_t \in (0,1)$ via a sigmoid activation, $\mathrm{sigmoid}(z) = 1/(1+e^{-z})$, and recovering both quantities in closed form from the resource constraint, $C_t = (1-s_t)\,z_t K_t^\alpha$ and $K_{t+1} = s_t\,z_t K_t^\alpha$. A softplus head on $C_t$ alone would guarantee $C_t>0$ but not $K_{t+1}>0$ (the network could output $C_t > z_t K_t^\alpha$). This sigmoid-savings parameterization removes an entire class of infeasible candidate policies before training begins; see the code listing in Section Section 2.4 above.

Soft constraint, minimized in the loss.

The only equilibrium condition that cannot be enforced analytically is the Euler equation (2.9). The squared relative Euler error (2.12) is averaged over the mini-batch and driven toward zero by stochastic gradient descent.

This split is pedagogically important for three reasons: (i) only the genuinely non-closed-form conditions enter the loss, which speeds up training; (ii) it eliminates a family of bad local minima in which the network produces, e.g., slightly negative consumption or infeasible states; and (iii) it explains why the loss typically converges to a small but nonzero value even at the optimum, since the Euler residual is intrinsic and cannot be removed by re-parameterization. Figure Figure 2.6 summarizes this construction for Brock--Mirman.

2.5.0.1How the split generalizes.¶

In models with more equilibrium objects (the OLG benchmark of Azinovic et al. (2022), the IRBC model of Chapter Chapter 3, the HA economies of Chapter Chapter 6), the same logic extends: firm first-order conditions for prices $(w_t,r_t)$ are closed-form in the aggregate state, the household budget constraint algebraically determines consumption given savings, and each inequality constraint contributes a softplus-headed KKT multiplier paired with a Fischer--Burmeister complementarity residual in the soft part of the loss (Chapter Chapter 3). The Brock--Mirman case above is the minimal instance of the pattern.

2.5.0.2Market-clearing layers.¶

One can push this design philosophy further by encoding the market-clearing condition itself into the network as a dedicated output layer rather than minimizing a market-clearing residual in the loss: the network outputs unnormalized cohort savings (or shares) and a final layer rescales them so that aggregate clearing holds by construction. Azinovic-Yang & Žemlička (2024) use such a “market-clearing layer” in an OLG economy with rare disasters; this is the discrete-time counterpart of the PINN-style practice of baking conservation laws directly into the network output (Chapter Chapter 7). Sigmoid heads, softplus heads, Fischer--Burmeister residuals, and market-clearing rescaling layers thus form a small toolbox of architecture-level encodings that each move part of the equilibrium structure from the soft loss into the hard part of the network.

2.6Quadrature Rules for Conditional Expectations¶

2.6.1Why We End Up Integrating, and What Numerical Integration Is¶

2.6.1.1Why an integral always shows up.¶

Sooner or later, every dynamic stochastic model in this script presents the same algorithmic bottleneck: a forward-looking agent has to form an expectation over future shocks before any decision can be made. The Euler equation (2.9) hinges on $\mathbb{E}_t[\,\alpha z_{t+1} K_{t+1}^{\alpha-1}/C_{t+1}\,]$; the Bellman operator behind a value-function iteration evaluates $\mathbb{E}[V(\bm{s}')\mid\bm{s},a]$ at every state and action; the relative Euler error (2.12) embeds the same expectation in the diagnostic; the integrated-assessment models of Chapter Chapter 11 require expected discounted utility under climate-shock distributions; and the structural-estimation moments of Chapter Chapter 10 are themselves expectations over simulated paths. Outside a handful of conjugate or fully-linear-quadratic-Gaussian special cases, none of these expectations admit closed-form expressions, so the integral $\mathbb{E}[g(\bm\varepsilon)] = \int g(\bm\varepsilon)\mu(\bm\varepsilon)\,d\bm\varepsilon$ has to be approximated numerically by a finite, cheap-to-evaluate, ideally differentiable, weighted sum $\sum_q w_q\, g(\bm\varepsilon_q)$. Choosing the nodes $\bm\varepsilon_q$ and weights $w_q$ well is the entire content of quadrature theory. The path-averaging recipe used in the Brock--Mirman code above is one such choice (a Monte Carlo sample average with one node per state along a simulated trajectory); the rest of this section makes the deterministic and quasi-random alternatives explicit and explains when each is preferable.

2.6.1.2Picture 1: a definite integral as area, and the Riemann/midpoint sum.¶

Strip away the economics. A definite integral $\int_a^b f(x)\,dx$ is the (signed) area between the graph of $f$ and the $x$-axis on $[a,b]$. The simplest deterministic numerical rule, the midpoint rule, replaces this area by a stack of $N$ rectangles of equal width $\Delta x = (b-a)/N$, each one as tall as $f$ at the midpoint of its base (Figure Figure 2.7, left). Adding the rectangle areas yields

for smooth $f$. Trapezoid and Simpson rules refine the same idea by replacing each rectangle with a trapezoid or a parabolic arc and reach $\mathcal{O}(N^{-2})$ and $\mathcal{O}(N^{-4})$ respectively; Gauss--Hermite, the workhorse of Section 2.6.2, is the optimal rule when the integrand is multiplied by the Gaussian weight $e^{-x^2}$ and reaches degree-$(2Q-1)$ exactness using only $Q$ nodes. The same tile-the-area idea generalizes to higher dimensions by laying out a Cartesian grid. With $N$ nodes per coordinate the cost is $N^d$; equivalently, with $M=N^d$ total nodes the midpoint rate becomes $\mathcal{O}(M^{-2/d})$. Notice that it is the exponent of the rate, not just the constant, that degrades from -2 in 1D to $-2/d$ in $d$-D Cartesian, the curse of dimensionality made quantitative. This is the explicit form of the curse of dimensionality flagged in Section Section 2.1, and it motivates both the Stroud monomial rules of Section 2.6.3 and the randomized methods of Section 2.6.4.

2.6.1.3Picture 2: throwing darts to estimate $\pi$.¶

An entirely different idea is to abandon the grid and approximate the integral by a sample average: draw $N$ random points $\bm{u}_1, \ldots, \bm{u}_N$ uniformly from the integration domain $\Omega$ and report $I_N = \mathrm{vol}(\Omega)\cdot \tfrac{1}{N}\sum_{i=1}^{N} f(\bm{u}_i)$. This is plain Monte Carlo (MC), and its error decays as $\mathcal{O}(N^{-1/2})$ with a rate that is independent of the dimension $d$, although the variance constant can still worsen with dimension. This is why MC dominates deterministic grids when $d$ is large. The cleanest illustration uses the unit square $[0,1]^2$ and the indicator function of a quarter-disc:

where $N_{\mathrm{in}}$ counts how many of the $N$ uniform “darts” land inside the quarter-circle $x^2+y^2 \leq 1$ (Figure Figure 2.7, right). With $N=100$ a typical run gives $\widehat{\pi}_{100} \approx 3.04$ (about 3% off); with $N=10^6$ a typical run gives $\widehat{\pi}_{10^6} \approx 3.1417$ (about 10^-4 off). The error shrinks as $\mathcal{O}(1/\sqrt{N})$, requiring a hundredfold increase in $N$ to gain one extra decimal of accuracy, which is glacially slow compared to $\mathcal{O}(N^{-4})$ for Simpson’s rule on a smooth 1D integrand. But the MC rate has no dependence on the dimension of the domain: replacing the quarter-disc by a $d$-dimensional unit ball would leave the rate untouched, while the deterministic grid would suffer the $N^d$ cost explosion of the curse of dimensionality. This is what makes MC and its quasi-random refinement (QMC, Section 2.6.4) the natural tools for the conditional expectations encountered in DEQNs at $d \gtrsim 10$.

2.6.1.4Where the rest of this section is going.¶

With this picture in hand, the design of every quadrature rule in the literature can be read as an answer to two questions: (i) where do we place the nodes $\bm\varepsilon_q$, and (ii) what weights $w_q$ do we attach to them? Tensor-product Gauss--Hermite (Section 2.6.2) places nodes deterministically on a Cartesian grid of Hermite roots; the Stroud-3 monomial rule of Section 2.6.3 places only $2d$ nodes on the principal axes and accepts a controlled bias on fourth-order moments in exchange for linear-in-$d$ scaling; the QMC construction of Section 2.6.4 places nodes from a low-discrepancy sequence in the unit cube and pulls them back through the inverse CDF. The cost--accuracy trade-offs differ dramatically with $d$, as Table Table 2.2 (page ) makes concrete. Chapter Chapter 3 returns to these numbers when scaling DEQNs to multi-country economies.

2.6.2Tensor-Product Gauss--Hermite¶

The classical Gauss--Hermite rule approximates integrals against the weight function $e^{-x^2}$:

where the $Q$ nodes $\{x_q\}$ are the roots of the $Q$-th Hermite polynomial $H_Q(x)$ and the weights are $\tilde{w}_q = 2^{Q-1} Q!\sqrt{\pi}/(Q^2 [H_{Q-1}(x_q)]^2)$. For expectations under the standard normal distribution, we apply the change of variables $\varepsilon = \sqrt{2}\, x$ to obtain:

The 1D rule (2.16) is exact for univariate polynomials in $\varepsilon$ of degree at most $2Q-1$, an attractive accuracy guarantee for smooth integrands.

2.6.2.1Worked example: Brock--Mirman Euler expectation.¶

In the Brock--Mirman model, the conditional expectation in the Euler equation (2.9) is one-dimensional:

Replacing path averaging by Gauss--Hermite with $Q=5$ nodes turns the residual (2.9) into a deterministic function of $(K_t, z_t)$ and the network parameters, eliminating the shock noise inside the loss while costing only five extra forward passes per state. This is the simplest concrete instance of the general construction below and a useful sanity check: at $Q=5$ the quadrature error is negligible relative to the training error in this benchmark, so a well-trained network should match the analytical Brock--Mirman policy to numerical tolerance.

For shock dimension $d > 1$, the multivariate expectation is computed via a tensor product of one-dimensional rules. Each multi-dimensional quadrature node is a $d$-tuple $(\varepsilon_1^{q_1}, \ldots, \varepsilon_d^{q_d})$ with weight $\prod_{j=1}^{d} w_{q_j}$. The total number of quadrature nodes grows as $Q^{d}$, which becomes prohibitive once $d$ is large Judd, 1998. For $d \geq 10$, the monomial rule of Section 2.6.3 or sparse-grid (Smolyak) alternatives can substantially reduce the computational cost: Gerstner & Griebel (1998) introduce the construction in numerical analysis, Heiss & Winschel (2008) apply it to econometric likelihoods, and Brumm & Scheidegger (2017) develop adaptive sparse grids tailored to dynamic-programming and equilibrium computations. The polynomial-versus-exponential gap depends on smoothness assumptions and the effective dimension of the integrand: sparse grids attain polynomial rates for sufficiently regular functions; QMC achieves close-to-$\mathcal{O}(1/M)$ rates under randomized constructions and finite-variation / low-effective-dimension conditions Sobol', 1967Niederreiter, 1992Owen, 1995Caflisch, 1998Novak & Woźniakowski, 2008, but neither method is universally polynomial.

2.6.3Monomial (Stroud-3) Cubature with Linear Scaling¶

The exponential cost $Q^{d}$ of the previous subsection is the price paid for being exact in the highest-degree univariate polynomial along each coordinate. In equilibrium-residual applications, however, the integrand $h(\bm\varepsilon')$ obtained by composing the policy network with model primitives is typically only mildly nonlinear in the shock vector, and reproducing every cross-coordinate monomial of total degree up to $2Q-1$ is overkill. Once one is willing to give up that high degree, dramatically cheaper rules become available.

The simplest such rule is the Stroud degree-3 monomial cubature Stroud, 1971, a cornerstone of the toolkit reviewed in Judd (1998) [§7.5] and Maliar & Maliar (2014) [§5.3] for large-scale dynamic models. For a $d$-dimensional standard normal expectation it uses only $2d$ nodes, all on the principal axes:

where $\bm{e}_k$ is the $k$-th standard basis vector in $\R^{d}$. All weights are equal to $1/(2d)$, and the nodes lie at the common radius $\sqrt{d}$ from the origin (so they expand outward as the dimension grows, consistent with the fact that the bulk of a high-dimensional Gaussian sits in a thin spherical shell, recalling the dimension-of-volumes discussion in Section Section 2.1). At $d=1$, the rule collapses to the two-point cubature $\{+1, -1\}$ with weights $\{\tfrac12, \tfrac12\}$, exact for polynomials in $\varepsilon$ up to degree three.

2.6.3.1Why it works (and where it stops).¶

Rule (2.18) integrates every monomial in $\bm\varepsilon'$ of total degree at most three exactly: the first moments vanish by ±-symmetry, the variances $\E{\varepsilon_i'^{\,2}}$ all evaluate to 1 (each axis contributes $\tfrac{1}{2d} \cdot 2 \cdot d = 1$), the cross-moments $\E{\varepsilon_i' \varepsilon_j'}$ ($i \neq j$) vanish because each node has only one nonzero coordinate, and the third moments vanish again by symmetry. Higher moments are not exact: $\E{\varepsilon_i'^{\,4}}$ is reproduced as $d$ rather than the truth 3, so the rule introduces a controlled bias proportional to the integrand’s fourth-order shock content. In the IRBC class of Chapter Chapter 3 this bias is empirically negligible at the Euler-equation tolerance one cares about ($\sim 10^{-3}$); see Pichler (2011) for a careful demonstration on a multi-country RBC and Maliar & Maliar (2014) [Table 5] for a broader cost--accuracy benchmark. When higher accuracy is required, Stroud’s degree-5 monomial rule with $2d^2 + 1$ nodes still scales polynomially, not exponentially Judd, 1998.

2.6.3.2Cost comparison.¶

At $Q=3$ nodes per dimension, the tensor-product rule of Section 2.6.2 costs $3^{d}$ evaluations per state, while (2.18) costs $2d$. Table Table 2.2 contrasts the two for the dimensionalities encountered later in the script. The monomial rule is the default integration scheme behind the production DEQN code for IRBC-type models in Chapter Chapter 3 once the shock dimension exceeds about five, dropped in by replacing a single quadrature kernel.

2.6.4Inverse-CDF Transform and Quasi--Monte Carlo¶

For very high-dimensional expectations ($d \geq 10$), even sparse-grid rules can become expensive, and, when the integrand contains material fourth-order shock content, the bias of the monomial rule (2.18) starts to dominate. An effective alternative is Quasi-Monte Carlo (QMC) integration combined with the inverse-CDF transform Judd, 1998. This method maps the unbounded domain of normal shocks $\R^{d}$ to the unit hypercube $[0,1]^{d}$ using the inverse normal CDF:

where $\bm{\varepsilon} \in \R^{d}$ is the vector of i.i.d. standard normal shocks, $\Phi^{-1}$ is the element-wise inverse standard normal CDF, and $\bm{u}_m$ are points from a low-discrepancy sequence (e.g., Sobol) on $[0,1]^{d}$. For sufficiently smooth integrands, randomized QMC often achieves error rates close to $\mathcal{O}(1/M)$ up to logarithmic factors, compared with the $\mathcal{O}(1/\sqrt{M})$ rate of standard Monte Carlo. This makes QMC highly effective in many high-dimensional applications, including the multi-country IRBC of Chapter Chapter 3. The companion notebook 07_Genz_Approximation_and_Loss_Functions.ipynb explores QMC integration using the Genz test functions, a standard suite of integrands for benchmarking high-dimensional quadrature methods.

2.7Automatic Differentiation for DEQNs¶

The quadrature rules of the previous section answer the question “how do we evaluate the expectation in the Euler equation?” This section answers the companion question that every DEQN application faces: “how do we evaluate the derivatives in the Euler equation, the marginal utility $u'(C_t)$, the marginal product $\partial Y / \partial K$, and the derivative of the value function $V'(K)$?” For the textbook Brock--Mirman model of Section 2.4 we derived all of these by hand. But every variation of the model, whether CRRA utility in place of log, CES production in place of Cobb--Douglas, a capital adjustment cost, or a borrowing constraint, would force us to redo pages of algebra before writing the loss. Automatic differentiation (AD) removes that tax: the user writes only the period payoff $\Pi$ of the model once, and the first-order conditions, the envelope theorem, and all higher-order sensitivities are computed exactly from the code that evaluates $\Pi$. The result is not a numerical approximation of the Euler equation: it is the textbook Euler equation, produced by a different mechanism.

2.7.1Three ways to take a derivative¶

There are three generic ways to compute a derivative of a programmable function $f:\R^n \to \R$ at a point $x_0$: symbolic, finite differences, and autodiff. Each has a distinct profile.

2.7.1.1Symbolic differentiation¶

uses a computer algebra system (Mathematica, SymPy) to manipulate the algebraic expression for $f$ into an algebraic expression for $f'$. Its output is exact and human-readable, and for clean analytic formulas it is ideal. Its two weaknesses are (i) expression swell: the chain rule applied to a deeply composed expression can produce a result with many more terms than the original, sometimes enough to defeat further symbolic manipulation; and (ii) it cannot handle arbitrary code with loops and conditional branches.

2.7.1.2Finite differences (FD)¶

approximates the derivative by the definition itself. For the common central-difference variant,

The geometric content of this formula is the mundane fact that the slope of a smooth curve at a point can be approximated by the slope of a nearby secant line. Figure Figure 2.8 makes this concrete: the true tangent at $x_0$ (red) is approximated by the secant connecting $(x_0 - h, f(x_0-h))$ to $(x_0+h, f(x_0+h))$ (blue dashed). As $h$ shrinks the secant rotates toward the tangent, and its slope converges to $f'(x_0)$; taking $h$ too small, however, forces the numerator $f(x_0+h) - f(x_0-h)$ to become the difference of two nearly equal floating-point numbers, at which point catastrophic cancellation dominates.

Two sources of error compete as $h$ changes. The truncation error $\tfrac{1}{6}f'''(x_0)\,h^2$ shrinks as $h$ decreases; the rounding error associated with computing the near-zero subtraction $f(x_0+h)-f(x_0-h)$ in floating-point arithmetic grows as $\epsilon/h$, where $\epsilon \approx 2.2\cdot 10^{-16}$ is machine precision in double precision. The total error is minimized at the step size that balances the two,

The practical consequence is that central FD loses roughly five digits of precision relative to the input precision. For second derivatives the loss is worse: Hessians obtained by FD are usually unusable for precision-critical work. FD has one undeniable advantage: it treats $f$ as a black box, requiring only the ability to evaluate $f$. For debugging or for a one-off comparative-statics check it is fine. For training a DEQN, where the gradient is used millions of times, it is badly suboptimal. Figure Figure 2.9 makes the trade-off visible.

2.7.1.3Automatic differentiation¶

exploits the fact that every piece of Python (or any other imperative language) that evaluates a numerical function is, at run-time, a composition of elementary operations ($+$, $-$, $\times$, $/$, $\exp$, $\log$, $\sin$, $\cos$, $\ldots$) whose derivatives are known in closed form. The chain rule composes these local derivatives into the derivative of the whole program, exactly. The cost is a small multiple of one function evaluation, typically 2--$4\times$ in reverse mode, and is independent of the number of inputs. There is no step-size $h$ to tune, and the result is exact to machine precision. For ML-scale problems with 10⁶ parameters and a scalar loss, AD is the only feasible method. The classic computer-science references are Baydin et al. (2018) and Margossian (2019); both motivate AD from machine-learning workloads and lay out the forward/reverse-mode taxonomy used below.

2.7.1.4Where do local derivatives come from? A tiny built-in table.¶

It is worth pausing on a question that beginners reasonably ask: “How does the computer know that the derivative of $\sin(x)$ is $\cos(x)$?” The answer is deflating but honest: it does not compute this from first principles. Every autodiff framework ships with a short, hand-written table of derivatives for the elementary operations it supports, a few dozen entries such as those in Table Table 2.3. When your program executes $y = \sin(x)$, the framework looks up the rule “gradient of $\sin$ is $\cos$” in that table and records $\cos(x)$ on the edge of the computational graph. The chain rule then composes those table entries. Autodiff is not a theorem prover; it is a library of primitive rules plus an automatic application of the chain rule. This explains both its power (every program expressible in terms of these primitives is differentiable) and its limits (genuinely new functions require extending the table).

This explanation also makes the limits of AD concrete. Operations absent from the table (a black-box solver call, a non-differentiable step like sorting or argmax) require either a custom rule (via @tf.custom_gradient) or a redesign of the code. The pitfalls in Section 2.7.4 are essentially cases where either the table’s entry is degenerate at a point (kinks, $\partial|x|/\partial x$ at $x=0$) or the composed gradient is numerically unstable even though each local rule is correct.

2.7.2Computational graph; forward and reverse modes¶

Every numerical function, once evaluated, corresponds to a directed acyclic computational graph whose nodes are elementary operations and whose edges carry intermediate values. Take the toy example $y = f(x) = x^2 + \sin(x)$ evaluated at $x_0=2$:

The values along the graph are $v_1=4$, $v_2=\sin(2) \approx 0.909$, $y \approx 4.909$. The edges carry local derivatives: $\partial v_1/\partial x = 2x = 4$, $\partial v_2/\partial x = \cos(x) \approx -0.416$, $\partial y/\partial v_1 = \partial y/\partial v_2 = 1$. AD combines the edge derivatives by the chain rule in one of two traversal orders. Figure Figure 2.10 shows the graph together with both traversals.

2.7.2.1Forward mode¶

carries a derivative tag $\dot v$ next to every value $v$ and updates both in a single forward pass through the graph. One seeds $\dot x = 1$ at the input; by the chain rule, $\dot v_1 = 4$, $\dot v_2 = -0.416$, and $\dot y = \dot v_1 + \dot v_2 = 3.584$, which is exactly $f'(2) = 2x + \cos x$ evaluated at $x=2$. The cost is one extra float per variable and one extra pass through the graph. For a function with $n$ inputs and $m$ outputs, the cost of the full Jacobian is $\mathcal{O}(n)$ forward passes; forward mode is therefore attractive when the number of inputs is small.

2.7.2.2Reverse mode¶

first evaluates $f$ forward, storing the computational graph and all intermediate values. It then walks the graph backwards, carrying a sensitivity $\bar v = \partial y / \partial v$ along each edge. Seeded with $\bar y = 1$ at the output, the backward pass accumulates

yielding at the input node $\bar x = \bar v_1 \cdot 4 + \bar v_2 \cdot (-0.416) = 1\cdot 4 + 1\cdot(-0.416) = 3.584$. The computational cost is 2--$4\times$ a single forward pass, and, crucially, one reverse pass produces the full gradient with respect to all inputs simultaneously. Reverse mode is what tf.GradientTape, torch.autograd, and jax.grad use by default. The price paid is memory: the entire forward graph must be stored for the backward pass. For extremely long simulations this can be a binding constraint; we return to the point in the pitfalls below.

2.7.2.3Which mode for DEQNs.¶

The DEQN loss is a scalar mean-squared Euler residual, computed from a network with $n \sim 10^3$ to 10⁵ parameters. Reverse mode produces the full gradient with respect to all network parameters in 2--$4\times$ one forward pass, a speedup of $n/4$ over forward mode. This is the same reason reverse mode is the workhorse of deep-learning training: it exactly fits the “few outputs, many inputs” regime.

2.7.3The autodiff Euler residual¶

We now apply autodiff to the very object we spent Section 2.4 deriving by hand: the Euler equation of the Brock--Mirman planner. Define the period payoff as a function of the current state and the current choice:

where the three argument slots are the state $K_{\text{in}}$, the choice $K_{\text{out}}$, and the exogenous shock $z_{\text{in}}$ (the same slot names the code listing below uses); applying $\Pi$ at a date $t$ means plugging $K_t$ into slot 1, $K_{t+1}$ into slot 2, and $z_t$ into slot 3. This is the only place the model enters. Change $u$, $Y$, or $\delta$ and nothing else in what follows needs to move. The Bellman equation of Section 2.4 then reads

2.7.3.1Notation: what do $\partial_1\Pi$ and $\partial_2\Pi$ mean?¶

Throughout this section the subscript names the slot of $\Pi$ being differentiated, not a time index. With the three-slot definition $\Pi(K_{\text{in}},K_{\text{out}},z_{\text{in}})$ of (2.24), we write

The first slot $K_{\text{in}}$ is the state, the second slot $K_{\text{out}}$ is the choice, the third slot $z_{\text{in}}$ is an exogenous parameter and is not differentiated. An expression like $\partial_2\Pi(K_t,K_{t+1},z_t)$ therefore denotes the derivative of $\Pi$ in its second slot, evaluated with $K_t$ plugged into slot 1, $K_{t+1}$ into slot 2, and $z_t$ into slot 3, so it equals $\partial\Pi/\partial K_{t+1}$. The expression $\partial_1\Pi(K_{t+1},K_{t+2},z_{t+1})$ denotes the derivative in the first slot, evaluated at the time-$(t+1)$ state pair, so it also equals $\partial\Pi/\partial K_{t+1}$ but for a different physical reason (because $K_{t+1}$ now sits in the state slot of the period-$t+1$ problem). This overloading is the whole point: the same partial expression handles the FOC in one period and the envelope term in the next.
